Panel Mount Ball Valve

Panel Mount Ball Valve

Model No. GV-154-P-BV

Features

  • Maximum working pressure:
    3000 psi (206 bar) at 38°C
  • Working temperature:
    From -54°C to 180°C with PEEK Packing.
  • A short handle gives a quarter-turn rust-free operation.
  • Valves with PTEF seats are supplied with short handles.
  • A robust pin is to create a positive stop.
  • The stem +with shoulder provides blowout proof design to maintain seal integrity at all pressure.
  • Optional sour gas service conforms to NACE Mr0175.
  • Ball valves are hydrostatically tested at the full rated pressure and low-pressure pneumatic at 70 psi.
  • 100% factory test
Panel-Mount-Ball-Valve

Description

Bill of Material

Sr. No. Description Material Qty
1 Body SS316 1
2 Adaptor SS316 2
3 Seat Ring DELRIN 2
4 Ball SS316 1
5 Stem SS316 1
6 Gland Seal PTFE 1
7 Gland Washer SS316 1
8 Gland Retainer SS316 1
9 Check Nut SS304 1
10 Handle Plastic 1
11 Grub Screw SS304 1

3000 PSI (NPT)

Model No. A B (SQ) C F (A/F)
YE-04-P-BV 55.0 25.0 1/8″NPT (F) 19.0
YE-08-P-BV 63.0 25.0 1/4″NPT (F) 19.0
YE-10-P-BV 65.0 25.0 3/8″NPT (F) 22.0
YE-15-P-BV 80.0 32.0 1/2″NPT (F) 27.0
YE-20-P-BV 95.0 40.0 3/4″NPT (F) 36.0
YE-25-P-BV 100.0 45.0 1″NPT (F) 41.0
